Rapsodo HITTING 2.0 Quick Start Guide

5. calıbratıon DISPLAYs
Connect the RCE to the
application and calibrate
the monitor. To calibrate
the monitor place a tee,
bat or person on the
center of home plate.
The red line in the
azimuth view should go
directly down the
middle of home plate
!
Angles should be as close to
90 degrees and 20 degrees
as possible
For additional user information download the
HITTING 2.0 user manual at
www.rapsodo.com/downloads
www.rapsodo.com
support@rapsodo.com
MAINTENANCE
RCE and Monitor
Connected
Ready to
record data
Data Processing
RCE and monitor connected
to application, needs
Calibrated or on ‘Pause Mode’
Battery Power
Connection to App
Monitor
RCE switched off
and charging
Warning for low battery,
please recharge monitor
RCE turned on, not
connected to app
and monitor
RCE turned on, connected to
app but not the monitor
HITTING 2.0
QUICK START GUIDE
The monitor and RCE
must be charged
separately to ensure a
complete charge for
each device.
BLUE
Processing
data (wait for
green light
to hit again)
GREEN
Data ready,
monitor ready
RED
Not ready
RED
Not connected
to RCE, Waiting
for USB Sync
GREEN
Successfully
Connected to
RCE through
USB
AMBER
Charging
(switched off)
GRAY
Off
USB Cables Charger
Federal Communication
Commission (FCC)
Interference Statement
The FCC Interference
Statement can be found
on our website,
www.rapsodo.com/fcc
