RATH MICROTECH SmartRescue 5 - Standard Surface Mount Dimensions

SmartRescue
Mounting Dimensions
(Standard Surface
Mount)
12.4 in
13.85 in
1.95
13.75 in in
4.00 in
Ø0.87
12.27 in
13.75 in
2.9 in
9.27 in
0.69 in
5.87 in
6.67 in
0.3 in
0.69 in
Ø0.8
Front
Back
Side
pg. 6
