Rath 2100-958NSR - Cabinet Mounting (2500-28 RC;36 RC;56 XRC;76 XRC;116 XRC)

Page 12
2500-28RC, 2500-36RC, 2500-56XRC, 2500-76XRC, 2500-76XRC, 2500-116XRC
Page 13
BACK PANEL
TOP
FRONT
SIDE
CABINET
TOP
SIDE
FRONT
17.06 [433.34]
5.19
[131.70]
Ø0.220
21.03
[534.29]
20.30 [515.62]
Ø0.220
Ø0.500
17.06
[433.34]
6.65 [168.92]
1.50 [38.10]
1.58 [40.01]
SIDE
6.88 [174.76] 6.88 [174.76]
6.30
[160.03]
6.30
[160.03]
7.93 [201.30]
1.50 [38.10]
1.38 [34.93]
0.86 [21.84]
