2100-958SR, SUBPNBX (back box only)
Page 5
A AA
SWITCH
LED
1 2 3
4 5 6
7 8 9
0 #
*
Enter
Record
Play/Pause
Stop
www.rathmicrotech.com
Rath Microtech 800-451-1460
RJ11C
PHONE JACK
24V AC/DC
J3
BATTERY
BACKUP
24V
AC/DC
SPADE PHONE
CONNECTION
ø0.19” [ø4.85]
9.75” [247.65]
12.50” [317.50]
6.00” [152.40]
3.00” [76.20]
5.50” [139.70]
2.25” [57.15]
8.00” [203.20]
1.50” [38.10]
5.50” [139.70]
1.20” [30.48]
0.59” [14.91]
0.89” [22.65]
R0.44” [R11.11]
1/8” HEX
INTERIOR ELEVATION
A
BACK BOX TOP
BACK BOX FRONT
COVER REARCOVER FRONT
BACK BOX BOTTOM
BACK BOX SIDE
0.12” [3.048]
