Setting up the Cellular Gateway
Included:
• 4G Cellular Gateway
• Antenna
Items Needed
Page 3
1. Open the Cellular Gateway by unscrewing the screw on the left side of the front cover with a Phillips screwdriver
and gently pull up on the left side.
2. Insert SIM card into J4 with the perforated edge rst and the gold contact side facing downward. Push until you
hear it click.
3. Screw in the antenna to J2 on the Cellular Gateway and ensure it is completely tightened.
Note: Only use antennas approved by. RATH
®
.
4. Connect the battery to J3.
J4J4
J2J2
Not Included:
• Phillips screwdriver
• Standard size AT&T GSM SIM card (25mm x 15mm) with voice and data
J3J3
