CALIBRATION INSTRUCTIONS rapidcount T 575
EN
5.
6.
Then press the “START“ button. Now place the
pink calibration card on the upper feed. Repeat
this process until “Image adjust sucess“ is
shown. Press the “REPORT“ button again to
get to “Size Dynamic Adjust“. Then press the
“START“ button.
Place all white calibration cards on the upper
feed. Repeat this process until “Size adjust
succes“ is shown. Finally, press the “MENU“
button 2 times to return to the counting mode.
pink
calibration card!
white
calibration cards!
ratiotec GmbH & Co. KG | Tel.: +49 201 361 490 | Fax: +49 201 361 49 26 | Email: info@ratio-tec.de
