Ravanson OG-500 - Types of Gas

A. Construction and characteristics
Transportable terrace/garden heater with tank housing.
Casing in steel with powder-coating or in stainless steel.
Gas hose connections with metal clamp (screw caps for Germany).
Heat emission from reflector.
B. Specifications
Use propane, butane or their mixtures gas only.
Max. wattage: 14000 watts
Min. wattage: 5000 watts
Consumption:
APPLIANCE CATEGORY:
I3+(28-30/37)
l3B/P(30)
I3B/P(50)
I3B/P(37)
TYPES OF GAS:
Butane
Propane
Butane,
propane or
their mixtures
Butane,
propane or
their mixtures
Butane,
propane or
their mixtures
GAS PRESSURE:
28-30mbar
37 mbar
30 mbar
50mbar
37mbar
OUTLET PRRESURE OF
REGULATOR:
30mbar
37 mbar
30 mbar
50mbar
37mbar
,
Using the proper regulator according to outlet pressure of regulator as showed in the table above.
C. Table of injector
APPLIANCE CATEGORY:
I3+(28-30/37)
l3B/P(30)
I3B/P(50)
I3B/P(37)
TYPES OF GAS:
Butane
Propane
Butane,
propane or
their mixtures
Butane,
propane or
their mixtures
Butane,
propane or
their mixtures
GAS PRESSURE:
28-30mbar
37 mbar
30 mbar
50mbar
37mbar
TOTAL HEAT
INPUT (Hs): (Qn)
14kW (G30:1019g/h; G31:1001g/h)
INJECTOR SIZE:
1.90 mm for main burner
0.22 mm for pilot burner
1.65 mm for
main burner
0.22 mm for
pilot burner
1.80 mm for
main burner
0.22 mm for
pilot burner
The marking, for example, 1.90 on the injector, indicates that the size of injector is 1.90 mm
The hose and regulator assembly must conform to local standard codes.
Regulator outlet pressure should meet the corresponding appliance category in B. Specification.
The appliance requires approved hose in 1,4m length.
