Ravanson PM-8500 User Manual

Figure C
Figure D
Window
adapter
Locking screw
Figure
E
Window
Window adapter
Draining hose
Hose
connector
Insert the hose connector into the window adapter (Fig. C). Adjust the adapter to the window width (vertically
or horizontally) and then tighten the screw to prevent the adapter displacement (Fig. D). Ensure the adapter
matches the window and stays in place. Close the window so as the adapter remains in the slot between the
window and the frame or the sill (Fig. E).
V. CONTROL PANEL
PM-8500S PM-9500S
PM-8500 PM-9500
3 7 5 4 6 2 1
