XI. POPULAR DEFECTS
PROBLEM CAUSE SOLUTION
The air-conditioner does not
switch on.
No power supply Plug the air-conditioner.
The water tank overflow indicator
is on
Empty the water tank
The air-conditioner restarts Direct sunlight Cover the windows
The doors and windows are open,
multiple heat sources in the room
Close the doors and windows,
remove the heat sources from the
room
Soiled filter Clean or remove the filter
Air inlet or outlet is obstructed Remove the obstacles
Noisy operation The air-conditioner is not level Put the air-conditioner on an even
surface to prevent vibrations
The compressor does not operate Active compressor protection This should not last over 3 minutes
Restart the air-conditioner
If the above-mentioned advice does not solve the problem, contact the repair service.
Technical parameters
Voltage 220-240 V
Frequency 50 Hz
Refrigerant/weight 410A/370g
The remote control Power supplied 2 x AA (3V d.c.)
PM-9500
PM-9500S
PM-8500
PM-8500S
Description Symbol Unit Value Value
Rated cooling efficiency P rated
Cooling
kW 2,6 2,0
Rated heating efficiency P rated
Heating
kW - -
Nominal power consumption
Cooling
P EER kW 1 0,9
Nominal power consumption
Heating
P COP kW - -
Rated energy efficiency ratio EERd - 2,6 2,6
Rated efficiency ratio COPd - - -
Power consumed with the thermostat off P TO W 131,1 131,1
Power consumption in standby mode P SB W 1 1
Power consumption of single-/dual-channel
air-conditioners
- Cooling
- Heating
DD: Q DD
SD: Q SD
DD: kWh/h
SD: kWh/h
0,9
-
0,9
-
Sound power L WA dB (A) 64 64
Global Warming Potential GWP kg CO
2
equivalents
1975 1975
Further information can be obtained from
RAVANSON LTD. Sp. z o.o.
ul. Mazowiecka 6, 09-100 Płońsk
The manufacturer reserves the right to introduce technical modifications!
