CALIBRATE ISO RAVEN STEERING CONTROLLER | CR7 AUTOSTEERING | RAVEN EUROPE GENERIC
PAGE 20/24 | Calibration manual | 016-8000-015EN | Rev. A
Go to the button with the satellite. Change
the GPS shutdown Timer from 0 to 1.
With this setting the receiver is powered on
for an hour when the CR7 is shut down. So it
keeps its accuracy.
When pressing the steering wheel button at
the top, information for the steering status is
shown. All statuses must be green except the
Resume Switch Status.
When pressing the Remote Go button (if
attached) this one should blink green.
When pressing the GPS button at the top,
information for the GPS is shown. The status
must be converged. The Current Accuracy is
the relative accuracy, which means accuracy
after one day. Pass to pass accuracy is not
shown.
