RG55T-R Operation • Service • Maintenance
40
Fuel Tank - Check Level, Fill & Drain
The fuel tank (1) is located on the left side of the
RG55T-R. View the fuel level gauge on the tank (2). If fuel
level is low, remove the fuel cap (3), carefully fill the fuel
tank with gasoline fuel only, and replace cap.
Note: ALWAYS use GASOLINE Fuel.
Fuel FIlter
The fuel filter (4) is located to the left of the fuel tank as
shown. Loosen the hose clamps and pull the fuel line away
from the filter on both ends. Replace the fuel filter (see quick
reference part #s listed in back of manual) Inspect the fuel
lines, to be sure of no cracks or sign of dry-rotting.
Note: Fuel lines should be replaced every year to meet
emissions requirements.
Draining the Fuel Tank
Rayco recommends draining the fuel tank once a year,
especially if the RG55T-R will be in storage for longer than
a month. To drain the tank, remove the fuel cap (3) to assist
in draining. Place a container under the tank on level ground,
and remove the fuel tank drain plug (5). Once the fuel has
been drained to best of its ability, insert drain plug back in
its location and tighten it securely. Be sure there is no fuel
leaking from drain plug when refilling the tank.
Maintenance
GASOLINE IS HIGHLY COMBUSTIBLE. DO NOT
SPILL IT ON THE ENGINE. LET THE ENGINE
COOL BEFORE REFUELING. DO NOT SMOKE
OR ALLOW ANY HOT OBJECTS NEARBY
WHEN REFUELING.
1
3
2
4
5
DO NOT REMOVE FUEL HOSE FOR AT LEAST 3
MINUTES AFTER STOPPING THE ENGINE.
NOTICE
Do Not wash the inside of the tank with water, or a
pressure hose of any kind.
