RG55T-R Operation • Service • Maintenance
54
FROM WIRE DESCRIPTION
GAUGE COLOR
TO
PLUG# PIN# (FUNCTION IMPRINT) PLUG# PIN #
1 1A CLUTCH RELAY SIGNAL 18 ORG 5 A6
1 1B BOOM UP SOL 18 WHT/GRN 62 A
1 2B BOOM DWN SOL 18 WHT/BLK 63 A
1 1C BLADE UP SOL 18 DGN SP10
1 2C BLADE DWN SOL 18 GRY/BLK SP11
1 1D 2 SPD RELAY SIG 18 ORG/BLK 66 A
1 1E SWING LEFT SOL 18 PUR 64 A
1 2E SWING RIGHT SOL 18 GRY 65 A
1 1F LEFT TRACK FWD 18 RED/WHT 77 A
1 2F LEFT TRACK REV 18 BRN 78 A
1 1G RIGHT TRACK FWD 18 DBU 67 A
1 2G RIGHT TRACK REV 18 VIO/BLK 68 A
1 1H COMMAND CUT SOL 18 RED/BLK SP25
1 3H COMMAND CUT RETURN 18 BLK SP28
1 1J GROUND 16 BLK SP2
1 2J GROUND 16 BLK SP2
1 3J GROUND 16 BLK SP2
1 1K POWER 16 WHT SP5
1 2K POWER 16 WHT SP5
1 3K POWER 16 WHT SP5
2 1A +CAN SEE NOTE Y LW SP26
2 2A + USB SEE NOTE GRN 17 3
2 3A - USB SEE NOTE WHT 17 2
2 3B - CAN SEE NOTE GRN SP27
2 1C POWER E-STOP DIODE 18 BLU/WHT 60 2
2 2C USB GND SEE NOTE BLK 17 4
2 3C USB 5V PWR SEE NOTE RED 17 1
2 2D GROUND 16 BLK SP2
2 3D POWER 16 WHT SP5
2 1E CLUTCH SW 18 ORG 10 4
2 1F THROTTLE DWN SW 18 DBU 20
2 2F THROTTLE UP SW 18 BRN 19
2 3F REMOTE/SOA SIG 18 ORG/WHT 59
3 A ENGINE ECM PWR 16 GRN 5 D11
3 C FUEL PUMP GND 16 BLK 26
3 D FUEL PUMP PWR 16 RED 27
3 F START SIGNAL 18 BRN 7 7
3 G MIL LAMP SIG 18 TAN SP19
4 E ENGINE ECM GND 16 BLK SP2
5 A1 PWR RELAY 30 14 RED 5 B11
5 A3 SAFETY INTERLOCK 86 16 BLU/WHT 31
5 A4 MAIN PWR 30 14 RED SP1
5 A11 FUSE IGN SW PWR 14 RED 6 1
5 A12 FUSE MAIN PWR 10 RED SP1
5 B1 GROUND 85 16 BLK SP2
5 B3 FUSE PWR 87 16 RED SP3
5 B4 GROUND 85 16 BLK SP2
5 B6 CLUTCH PWR 87 14 DBU SP22
5 B12 FUSE MAIN PWR 10 RED SP1
5 C4 HARNESS PWR 30 16 PNK SP4
5 C6 SOA SAFETY SIG 16 BLK/YLW SP12
5 C11 HARNESS PWR 16 PNK SP4
5 C12 FUSE PWR 16 RED SP3
39931 Main Wire Harness
