RG55T-R Operation • Service • Maintenance
800.392.2686
55
39931 Main Wire Harness
5 D4 GROUND 85 16 BLK SP2
5 D6 BLADE SOL 87 16 YLW SP14
5 D12 FUSE PWR 16 RED SP3
7 5 ECM POWER 16 WHT SP5
8 85 GROUND 16 BLK SP2
8 86 SIGNAL IN 18 WHT SP5
8 87A SUPPLY PWR 18 WHT SP5
8 30 E-STOP RLY SIG 18 BLU/WHT 61 2
9 A CLUTCH GND 14 BLK SP2
9 B CLUCTH PWR 87 14 DBU SP22
10 1 CLUTCH SW PWR 16 PNK SP4
11 MIL LAMP PWR 18 PNK SP4
12 A BLADE DWN SW 18 LBU SP7
12 B BLADE UP SW 18 TAN SP6
12 C SW PWR 18 PNK SP4
13 A SWING L SW 18 PUR SP9
13 B SWING R SW 18 GRY SP8
13 C SW PWR 18 PNK SP4
14 A BOOM DWN SW 18 WHT/BLK SP16
14 B BOOM UP SW 18 WHT/GRN SP15
14 C SW PWR 18 PNK SP4
15 A LEFT TRACK REV SW 18 BRN SP24
15 B LEFT TRACK FWD SW 18 RED/WHT SP23
15 C SW PWR 18 PNK SP4
16 A RIGHT TRACK REV SW 18 VIO/BLK SP18
16 B RIGHT TRACK FWD SW 18 DBU SP17
16 C SW PWR 18 PNK SP4
18 THROTTLE SW PWR 18 PNK SP4
21 CHASSIS GND 16 BLK SP2
22 ENG GND 16 BLK SP2
23 SOA GND 16 BLK SP2
24 2 SPD SW PWR 18 PNK SP4
25 2 SPD SIG 18 ORG/BLK SP20
28 MAIN PWR 10 RED SP1
29 PWR BREAKER 10 RED 30
32 SAFETY INTERLOCK IN 18 BLU/WHT 33 2
33 1 E-STOP SIG 18 BLU/WHT SP21
34 1 BLADE/BOOM DIVERT SOL 18 YLW SP14
34 2 BLADE/BOOM DIVERT SOL GND 18 BLK SP2
35 1 BLADE/BOOM DIVERT SOL 18 YLW SP14
35 2 BLADE/BOOM DIVERT SOL GND 18 BLK SP2
36 1 2 SPD SOL SIG 18 ORG/BLK SP20
36 2 2 SPD SOL GND 18 BLK SP2
37 1 TRACK IN SOL 18 LGN SP29
37 2 TRACK IN GND 18 BLK SP2
38 1 TRACK OUT SOL 18 ORG SP30
38 2 TRACK OUT GND 18 BLK SP2
39 1 RIGHT TRACK REV SOL 18 VIO/BLK SP18
39 2 RIGHT TRACK GND 18 BLK SP2
40 1 RIGHT TRACK FWD SOL 18 DBU SP17
40 2 RIGHT TRACK GND 18 BLK SP2
41 1 LEFT TRACK REV SOL 18 BRN SP24
41 2 LEFT TRACK GND 18 BLK SP2
42 1 LEFT TRACK FWD SOL 18 RED/WHT SP23
42 2 LEFT TRACK GND 18 BLK SP2
43 A COMMAND CUT SOL 18 RED/BLK SP25
43 B COMMAND CUT RETURN 18 BLK SP28
44 1 BOOM UP SOL 18 WHT/GRN SP15
44 2 BOOM UP GND 18 BLK SP2
45 1 BOOM DWN SOL 18 WHT/BLK SP16
45 2 BOOM DWN GND 18 BLK SP2
46 1 BLADE UP/ BOOM SWING R 18 GRY SP8
46 2 BLADE UP/ BOOM SWING GND 18 BLK SP2
47 1 BLADE DWN/ BOOM SWING L 18 PUR SP9
