RG55T-R Operation • Service • Maintenance
56
47 2 BLADE DWN/ BOOM SWING GND 18 BLK SP2
48 1 DIODE 1 CATHODE 18 GRY SP8
48 2 DIODE 1 ANODE 18 DGN SP10
49 1 DIODE 2 CATHODE 18 PUR SP9
49 2 DIODE 2 ANODE 18 GRY/BLK SP11
50 1 DIODE 3 CATHODE 18 BLK/YLW SP12
50 2 DIODE 3 ANODE 18 DGN SP10
51 1 DIODE 4 CATHODE 18 BLK/YLW SP12
51 2 DIODE 4 ANODE 18 GRY/BLK SP11
52 1 DIODE 5 CATHODE 18 PUR SP9
52 2 DIODE 5 ANODE 18 LBU SP7
53 1 DIODE 6 CATHODE 18 GRY SP8
53 2 DIODE 6 ANODE 18 TA N SP6
54 1 DIODE 7 CATHODE 18 ORG/BLK SP13
54 2 DIODE 7 ANODE 18 LBU SP7
55 1 DIODE 8 CATHODE 18 ORG/BLK SP13
55 2 DIODE 8 ANODE 18 TA N SP6
56 SOA SAFETY SW 18 ORG/BLK SP13
57 SOA SAFETY SIG 18 BLK/YLW SP12
58 REMOTE/SOA SWITCH 18 PNK SP4
60 1 E-STOP PWR DIODE 18 BLU/WHT SP21
61 1 E-STOP RELAY DIODE 18 BLU/WHT SP21
62 C DIODE CATHODE 18 WHT/GRN SP15
63 C DIODE CATHODE 18 WHT/BLK SP16
64 C DIODE CATHODE 18 PUR SP9
65 C DIODE CATHODE 18 GRY SP8
66 C DIODE CATHODE 18 ORG/BLK SP20
67 C DIODE CATHODE 18 DBU SP17
68 C DIODE CATHODE 18 VIO/BLK SP18
69 1 DIODE CATHODE 18 WHT/GRN SP15
69 2 DIODE ANODE 18 LGN SP29
70 1 DIODE CATHODE 18 WHT/BLK SP16
70 2 DIODE ANODE 18 ORG SP30
71 TRACK IN/OUT SW PWR 18 PNK SP4
72 A DIODE ANODE 18 BLK SP28
72 C DIODE CATHODE 18 RED/BLK SP25
73 A DIODE ANODE 18 BLK SP2
73 C DIODE CATHODE 14 DBU SP22
74 A DIODE ANODE 18 BLK SP2
74 C DIODE CATHODE 18 ORG/BLK SP20
75 MIL LAMP SIG 18 TA N SP19
76 A RESISTOR 500 OHM 18 PNK SP4
76 B RESISTOR 500 OHM 18 TAN SP19
77 C DIODE CATHODE 18 RED/WHT SP23
78 C DIODE CATHODE 18 BRN SP24
79 TRACK IN SOL 18 LG N SP29
80 TRACK OUT SOL 18 ORG SP30
81 A 120 OHM RESISTOR 18 YLW SP26
81 B 120 OHM RESISTOR 18 GRN SP27
39931 Main Wire Harness
