Rayco RG55T-R User Manual

RG55T-R Operation • Service • Maintenance
800.392.2686
57
SPLICE CIRCUITS
SPLICE WIRE DESCRIPTION GAUGE COLOR CONNECTED TO
SP1 MAIN POWER 10,14 RED 5-A4, 5-A12, 5-B12, 28
SP2 GROUND 14,16,18 BLK
1-1J, 1-2J, 1-3J, 2-2D, 4-E, 5-B1, 5-B4, 5-D4, 8-85, 9-A, 21,22,23,34-2,35-
2,36-2, 37-2, 38-2, 39-2, 40-2, 41-2, 42-2, 44-2, 45-2, 46-2, 47-2, 73-A,
74-A
SP3 FUSE POWER 14 RED 5-B3, 5-C12, 5-D12
SP4 HARNESS POWER 16 PNK 5-C4, 5-C11, 10-1, 11, 12-C, 13-C, 14-C, 15-C, 16-C, 18, 24,58, 71, 76-A,
SP5 LCM POWER 16 WHT 1-1K, 1-2K, 1-3K, 2-3D, 7-5, 8-86, 8-87A
SP6 BLADE UP SW 18 TAN 12-B, 53-2, 55-2
SP7 BLADE DN SW 18 LBU 12-A, 52-2, 54-2
SP8
BLADE U/ SWING R
SOL
18 GRY 13-B, 46-1, 48-1, 53-1, 65-C
SP9
BLADE D/ SWING L
SOL
18 PUR 13-A, 47-1, 49-1, 52-1, 64-C
SP10 BLADE UP LCM 18 DGN 1-1C, 48-2, 50-2
SP11 BLADE DWN LCM 18 GRY/BLK 1-2C, 49-2, 51-2
SP12 BLADE RELAY 18 BLK/YLW 5-C6, 50-1, 51-1, 57
SP13 SOA SWITCH PWR 18 ORG/BLK 54-1, 55-1, 56
SP14 BLADE SOL 18 YLW 5-D6, 34-1, 35-1
SP15 BOOM UP SOL 18 WHT/GRN 14-B, 44-1, 62-C, 69-1
SP16 BOOM DWN SOL 18 WHT/BLK 14-A, 45-1, 63-C, 70-1
SP17 RIGHT TRACK FWD
SOL
18 DBU 16-B, 40-1, 67-C
SP18 RIGHT TRACK REV SOL 18 VIO/BLK 16-A, 39-1, 68-C
SP19 MIL LAMP SIG 18 TAN 3-G, 75, 76-B
SP20 2 SPD SIG 18 ORG/BLK 25, 36-1, 66-C, 74-C
SP21 E-STOP POWER 18 BLU/WHT 33-1, 60-1, 61-1
SP22 CLUTCH PWR 14 DBU 5-B6, 9-B, 73-C
SP23 LEFT TRACK FWD SOL 18 RED/WHT 15-B, 42-1, 77-C
SP24 LEFT TRACK REV SOL 18 BRN 15-A, 41-1, 78-C
SP25 COMMAND CUT SOL 18 RED/BLK 1-1H, 43-A, 72-C
SP26 CAN + SEE NOTE 02-1A, 03-N, 81-A
SP27 CAN - SEE NOTE 02-3B, 03-P, 81-B
SP28 COMMAND CUT
RETURN
18 BLK 1-3H, 43-B, 72-A
SP29 TRACK IN SOL 18 LGN 37-1, 69-2, 79
SP30 TRACK OUT SOL 18 ORG 38-1, 70-2, 80
39931 Main Wire Harness
