16 RAYTECH Switzerland
Transformer type Winding Measurement
Vector Group Phase HV Winding LV Winding
A H1-H3 X3-X1
D-d 6 B H2-H1 X1-X2
C H3-H2 X2-X3
A H1-H3 X2-X1
D-d 8 B H2-H1 X3-X2
C H3-H2 X1-X3
A H1-H3 X2-X3
D-d 10 B H2-H1 X3-X1
C H3-H2 X1-X2
A H1-H3 X1-X0
D-yn 1 B H2-H1 X2-X0
C H3-H2 X3-X0
A H1-H3 X0-X2
D-yn 3 B H2-H1 X0-X3
C H3-H2 X0-X1
A H1-H3 X3-X0
D-yn 5 B H2-H1 X1-X0
C H3-H2 X2-X0
A H1-H3 X0-X1
D-yn 7 B H2-H1 X0-X2
C H3-H2 X0-X3
A H1-H3 X2-X0
D-yn 9 B H2-H1 X3-X0
C H3-H2 X1-X0
A H1-H3 X0-X3
D-yn 11 B H2-H1 X0-X1
C H3-H2 X0-X2
