Raytech TR-1P - Table of Contents

All rights reserved. No portion may be reproduced without written consent
1 RAYTECH Switzerland
0 – 1
Table of Contents
Section
Page
Table of Contents 0 – 1 1
Safety Precautions 1 – 0 2
Uncrating Procedure 2 – 0 3
Introduction 3 – 0 4
Technical Specifications 4 – 0 5
Transformer Ratio Testing 5 – 0 7
Important note 8
Operating Instructions 6 – 0 9
Current Transformers 7 – 0 11
Three Phase Transformers 8 – 0 12
Configuration Charts 8 – 0 13
Three Phase Transformer results 8 – 1 21
Warranty 9 – 0 23
