Example: Measuring a Y:D transformer:
The TR-1 Displays: 12.73
The Turns-Ratio is: 12.73 * 2 / 3 = 8.48667
( column 2 )
The Voltage-Ratio is: 12.73 * 2 / sqrt3 = 14.6993
( column 3 )
or Voltage-Ratio is: 8.48667 * sqrt3 = 14.6993
( column 4 )
