I MON / TXKey
l , When pressed, selects the Monitor mode and ‘MON” and ‘wx appear on the LCD. In
. this mode, the radio will monitor the currently selected working channel and the priority
channel (16~1~s) and also the last used weather channel is monitored for severe
weather alert broadcasts.
l When pressed, and held for 1 second, a beep will be heard and the transmit output
power setting alternately changes between 5 and 1 Watt.
IGPLUS Key
This key is used to instantly select the priority channel (16~1~s). CH16 is the default
priority channel from the factory. However an alternate channel can be programmed
as the priority channel if desired.
A/V Channel Keys
The up and down arrow keys are used to change the currently selected channel. The
channel number is increased or decreased once with each keypress or if held, will
continue scrolling through the channels until released.
9
5
o-
3
Fig. 3-l LAYOUT OF CONTROLS
