REPAIR AND MAINTENANCE
WARNING:
To prevent shock, please follow the
instructions accordingly and do not
skip or combine any steps.
1 Lift up the seat and unscrew the
four (4) Phillips head screws in the
storage compartment and remove
the tray.
3 Remove the fuse and replace
with a new one of equal
amperage.
Note: Amperage rating is
located on top of fuse.
4 Close the fuse box. Replace
seat/storage compartment
with the four (4) Phillips head
screws.
Amperage
number
2 Locate fuse box on top of
battery. Open the fuse cover to
expose the fuse.
7 Tighten the brake housing
anchor securely.
8 Re-attach the chain guard. Test
ride and readjust as needed.
q Replacing the Fuse
Tools required: Phillips screwdriver
Turn power switch OFF.
