Razor E125 User Manual

6
REPAIR AND MAINTENANCE
❑
Adjusting the Chain
Tools required:
10
mm wrench,
two (2)
8
mm
wrenches
,
and
two (2) 1
7
mm
wrenches
.
1
U
sing two 17mm wrenches,
l
oosen the rear axle bolts by
turning the wrenches counter
clockwise.
2
Using two 8mm wrenches,
loosen the brake housing anchor
which is located in the long slot
on the left side of the rear fork.
3
Using a 10mm wrench,
tighten the tension adjusters on
the axle 1/8 to 1/4 turn to fi ne-
tune the chain tension. Both
adjusters must be tightened the
exact same amount to maintain
wheel alignment.
4
Once the tension is correct,
tighten the axle and brake an-
chor bolt. Test run the scooter.
Readjust as needed.
Note:
This system of adjusters
is common to motorcycles and
BMX bicycles. If you are not
familiar with it or do not feel
comfortable performing the ad-
justment, consult an authorized
Razor service center or a quali-
fi ed BMX bike or motorcycle
mechanic.
The chain should be “just taut”
– in other words snug, but not
piano-wire tight. The tension
should be similar to the fan
chain on an automobile. BE
CAREFUL NOT TO ADJUST TOO
TIGHT. The tensioning system
can easily impart too much ten-
sion and snap the chain or bend
the motor shaft. Adjust 1/8 to
1/4 turn at a time and check the
tension each time.
E_Series_Manualv10.indd 7 3/10/06 2:11:01 PM

Razor E125 Specifications

General

Max Speed	10 mph
Run Time	Up to 40 minutes of continuous use
Weight Limit	120 lbs
Frame	Steel
Throttle	Twist-grip
Recommended Age	8 and up
Deck	Full-size deck
Charge Time	12 hours
Brake	Hand-operated front brake
Tires	8-inch pneumatic
Kickstand	Retractable
Handlebar	Adjustable-height
Battery	24V (two 12V) sealed lead-acid, rechargeable
