Razor E150 User Manual

9
REPAIR AND MAINTENANCE
1 (E100 only, other
models go to Step 2)
Loosen the brake pad bolt and
remove one brake pad.
q Front Tire Replacement
Tools required: 10mm wrench, two (2) 17mm wrenches and a flathead screwdriver.
2 Using two 17mm wrenches,
loosen the front axle bolts by
turning the wrenches counter
clockwise.
3 Remove wheel and replace
tire. To reinstall wheel, reverse
these steps. Helpful hint: You
may need to use a flathead
screwdriver to center the axil
and the bolts.

Razor E150 Specifications

General

Weight Capacity	120 lbs (54 kg)
Battery	24V (two 12V) sealed lead acid
Motor	Single-speed, chain-driven, high-torque motor
Run Time	40 minutes of continuous use
Charge Time	12 hours
Frame	Steel
Tire Size	8-inch pneumatic front tire
Brakes	Hand-operated
