Razor E150 User Manual

8
REPAIR AND MAINTENANCE
10 Install the axle adjusters
and axle nuts. Tighten until they
just barely hold the hardware
in place.
11 Tighten both axle adjust-
ers the same number of turns
to fine-tune the tension on the
chain and to approximately
maintain the centering of the
wheel.
12 Tighten the brake housing
anchor securely. Test ride and
check. Readjust as needed.
13 Replace the chain guard.

Razor E150 Specifications

General

Weight Capacity	120 lbs (54 kg)
Battery	24V (two 12V) sealed lead acid
Motor	Single-speed, chain-driven, high-torque motor
Run Time	40 minutes of continuous use
Charge Time	12 hours
Frame	Steel
Tire Size	8-inch pneumatic front tire
Brakes	Hand-operated
