Razor e300 Instructions

Step 3: Replace the Stem Bolt
Unscrew the original stem bolt from the wedge
and remove. Insert the longer replacement bolt
[3a] and the washer [3b] and thread the wedge
[3c] in place until the bolt is 2 or 3 threads from the
end. Do not tighten all the way.
Insert the folding system as shown. Insert all the
way so the bottom plate of the folding system is
touching the headset lock nut.
Step 4: Reinstall Folding System
Need Help? Visit our website for additional instructions at www.razorusa.com or call toll-free at 866-467-2967 Monday - Friday
8:00am - 5:00pm Pacific Time.
Step 5: Steering Alignment
With the folding system aligned roughly with the front wheel, lightly tighten the stem bolt. Upright the T-bar and
visually check the alignment of the front wheel to the handlebar.
Carefully nudge the steering into alignment. When you are satisfied with the adjustment, fold the T-bar down
and tighten the stem bolt securely as shown below. The correct tightness is when the front fork and wheel are
securely clamped to the folding system and it can’t be twisted out of alignment with any normal use or force.
Step 6: Check Alignment
Take the scooter on a test ride to verify that the handlebar is properly aligned with the front wheel. If not, loosen
the stem bolt and adjust accordingly. When satisfied, recheck all fasteners before riding your scooter.
3a
3b
3c
2

Razor e300 Specifications

General

Foldable	No
Maximum speed	24 km/h
Product color	Silver
Built-in display	-
Maximum load weight	100 kg
Recommended age (min)	13 yr(s)
Battery life	40 min
Battery voltage	24 V
Manual	Yes

Weight and Dimensions

Depth	430 mm
Width	1040 mm
Height	1070 mm
Weight	21000 g
