RC watt's up WU100 User Manual

Features and Specifications 4
2 FEATURES AND SPECIFICATIONS
2.1 Features
 Measures energy (Wh), charge (Ah), power (W), current (A) and voltage (V)
 Connector to use an optional receiver battery for measurement down to 0 V
 Accurate & precise – 0.01 A current and 0.01 V voltage resolutions
 Measures peak Amps, peak Watts (except for Doc Wattson) and voltage
minimum (sag)
 Rugged – handles 50 A continuous and 100 A peak at 60 V
 14 ga., super fine stranded, high temperature, silicone rubber insulated wire
 Small & light with a tough plastic case available in several colors
 Acts like a wire so doesn't affect model's performance. Precision Alu-Chrom
current sensing resistor, with only 0.001 Ohms resistance and circuitry that draws only 7 mA
 Uses DSP to increase ADC resolution and differential measurement amplifiers to
increase noise immunity
 Factory calibration stores constants in EEPROM to compensate for component
tolerances
 Powerful, 8 MIPS micro-controller
 Made in USA to ISO 9001:2000 quality standards
 One-year warranty and complete user manual
2.2 Specifications Tables
Table 1 Electrical Measurement Ranges
Parameter Range Resolution Notes
Voltage 0* - 60 V 0.01 V *0 V min. w/ auxiliary power.
E.g. a receiver battery. Else 4.0
V.
Current 0 – 100 A peak 0.01 A 50 A continuous
Power 0 - 6554 W 0.1 W
Charge 0 - 65 Ah 0.001 Ah 0 – 6554 Ah for Doc Wattson.
0.1Ah resolution
Energy 0 - 6554 Wh 0.1 Wh 0 – 655 Kwh for Doc Wattson.
0.01KWh resolution
Table 2 Miscellaneous Specifications
Parameter Value Notes
Measurement Update Period 400 mS 650 mS for Doc
Wattson
Signal Sampling Rate ???? samples/s
Data Queue Sequence
time
2 seconds
In Circuit Resistance 0.001 Ohms
Operation Current 7 mA
Auxiliary Power Voltage 4.0 V - 60 V e.g. from a receiver
battery
Dimensions 2.8" L x 1.7" W x 0.83" D
Weight 2.3 oz. 1.7 oz. without case
Display Screen 16 character x 2 row STN
LCD
Nominal Operating
Conditions
0 - 50 C ambient
temperature, non
condensing humidity
Maximum
temperature must be
reduced at
maximum current
rating
"Watt's Up" & "Doc Wattson" Watt Meter and Power Analyzer User's Manual RC Electronics, Inc.
