TV 46LB45RQ is packaged with the TV stand separated from the cabinet. To setup the TV table stand, please carry out
the installation according to the instructions below.
The LCD panel can be scratched easily, so please:
1. Choose an absolutely flat surface to place the TV on.
2. Use soft cloth or cushion to face the TV panel.
Do not put TV on the table directly.
Always unplug the AC cord first when installing/removing
the stand.
Step One
Place the TV faced down on a soft cloth or cushion to prevent the
LCD panel from being damaged.
Step Three
Take the base. Please align four holes of the base and four
screwholes of the neck, insert the base to the neck, and then
insert the 4 screws and tighten them.
Step Two
Insert the neck into the opening on the bottom of the TV, and
then insert the 4 screws into the 4 holes on the neck and
tighten them.
9
TV Stand Installation
RS01TB410H
Pedestal Screws Quantity Part #
4pcsM4 x 10mm
RS01TB412H
Pedestal Screws Quantity Part #
4pcsM4 x 12mm
To Next Page
