Connections and Setup Chapter 1
Buttons and Other Jacks on Your TV/DVD
Side Input Jacks
Headphones Allows you to connect headphones to listen to the sound coming from the TV.
VIDEO INPUT 2 Receives video from another component such as a camcorder, video game console,
VCR, or DVD player. To access a component connected to the VIDEO jack, press the INPUT button on
your remote repeatedly to select VID2, displayed at the top of the screen.
AUDIO L and R Receives audio from another component such as a camcorder, video game console,
VCR, or DVD player. Use when connecting to the VIDEO or S-VIDEO INPUT. For mono audio sources, be
sure to use the L AUDIO input.
S-VIDEO INPUT Allows you to connect an S-Video cable from another component. Make sure you
also connect audio cables from the component to the TV. To access a component connected to the
S-VIDEO jack, press the INPUT button on your remote repeatedly to select S-VIDEO displayed at the top
of the screen.
USB For factory service use only
Side Panel Buttons
If you cannot locate your remote, you can use the side panel buttons on your TV to operate many TV
features.
POWER Turns the TV on and off.
MENU/(OK) Brings up the TV Main Menu. When in the menu system, it displays sub-menus and
selects highlighted items.
VOL
Increases the volume. In the TV menu system, it acts like the right arrow on the remote control
and can be used to select menu options.
VOL
Decreases the volume. In the TV menu system, it acts like the left arrow on the remote control
and can be used to select menu options.
CH
Scans up through the channel list. In the TV menu system, it acts like the up arrow on the remote
control and can be used to select menu options.
CH
Scans down through the channel list. In the TV menu system, it acts like the down arrow on the
remote control and can be used to select menu options.
Note: Do not connect
an S-Video and a
regular video cable to
the side jacks at the
same time.
