OPERATION
06
Install the leveling foot and the bottom hinge backet on the new bottom side. Then
tighten the bottom hinge bracket.
Slot the appliance door into the bottom hinge pin. Replace the upper hinge bracket on the new side
and check the fitting between the door/hinge moving smoothly. Then tighten the screws of the
upper hinge bracket. Replace the hinge cover and the right side screw covers. Then tighten the
the top hinge cover.
4
Check that the door is aligned horizontally and vertically and that the seals are closed on all sides
before finally tightening the upper hinge. Readjust the leveling feet.
5
3
