RCA RPW116 - Installing the Noise Damper Plate; Noise Damper Plate Installation Guide; Connecting the Cold Water Supply Hose; Water Inlet Hose Connection Procedure

1. Connect the water inlet hose to the
faucet by turning the connecting nut.
2. Then connect the other end of water
inlet hose to the cold connector in
water mixing valve by turning the
connecting nut.
Rubber ring seal
CONNECTING
NUT
CONNECTING
NUT
Be sure a rubber ring is inside the connecting nut.
COLD WATER
CONNECTOR
WATER
INLET HOSE
8
