Parts identification of the washer
Instruction of the washer operation panel
Inlet hose 1pc
Accessories
Please refer to the real material as the attachment
Top lid
Lint filter
Control panel
Cabinet
Drain hose
Inner tub
Impeller
Detergent dispenser
Adjustable leg
Power plug
11
12
Rinse setting
Press the button , you can choose between 1-4 times rinse.
Delay
Each time we press the preset button, the preset time
is added by 1hr. For more than 24hrs preset time, each
press of the button would add 6hrs. preset time can be
set up to 48 hrs. When the light of preset is on, it means
the preset time, or no preset time.
Program setting
Select wash program of [ ], ], white , ,
[child`s clothes],[color], [economic] and [wool].
heavy [normal [ ] [jeans]
The indicator light moves to the selected program. The
expected water level, no of rinses and total time to complete
the program will be displayed in the indicator.
Environment protect
We can select “energy saving”, water saving quiet operation,
Water temperature
press the button to select different temperature water for washing .
when the "hot"is on ,it does not means washing machine will use
water supplied by the water inlet
Start/pause
After program selection, press the button to start. The
flashing indicator light will indicate that selected program
is working and its current states. Press the button to pause
the operation during the wash program, repressing of button
will continue the program till the program is finished.
ON/OFF switch
When “ON/OFF” button is pressed, the washing machine is in
working state, and starts in standard program.
During the operation if the button is pressed ,
wouldend the running program, and is in the state of power off.
“ON/OFF” it
If drawing is changed, no inform any more.
1
2
3
4
5
6
7
8 9
1
2
3
4
5
6
7
8
9
Load Size select
Selection of function
START
PAUSE
ON/OFF
HEAVY
LOA D SIZE
Press “Load size” button, the user can set water level freely.
LED display :“1”(small)、“2”(medium)、“3”(large)
sma ll
medium
large
2
3
1
JEANS
1.The function display light Indicate that a selected feature
is ON or what the cycle is about to begin.
2.During the wash cycle ,the light indicates the current
STATUS of wash/ rinse /spin cycle.
