7
Attach the Wall Mount Bracket (not included)
Before you begin the third-party manufacturer instructions, be sure to do the following things:
1. Place the TV face down on a clean, safe and cushioned surface.
2. Remove the TV stand if you already attached it.
3. Place the spacers (not included) in the corresponding bracket holes.
CAUTION:
• When you attach the mount, be sure to use the spacers ( provided by the third-party
manufacturer ) between the TV and the bracket.
• To prevent internal damage to the TV and ensure it is mounted securely, be sure to use fixing
screws (not provided) that are 8 mm in length when measured from the attaching surface of
the mounting hook.
Wall mount hole pattern VESA (mm)
200 × 100
Wall mount screw size (mm)
M4
Follow instructions provided with the wall mount bracket.
• To complete the installation, please contact the wall mount manufacturer or the retailer from
which you purchased the TV.
• The selected screws are 8 mm in length when measured from the attaching surface of the rear
cover. The diameter and length of the screws differ depending on the wall mount bracket model.
NOTE: The diameter and length of the screws differ depending on the wall mount bracket
model.
8 mm
Wall mount bracket
Screw
Spacer
