INSTALLATION
Front panel
1. Remote control sensor.
2. Indicator LED:
RED STAND BY.
3. Key board.
REAR Connections
SIDE Connections
All the terminals are (from left to right):
AUDIO INPUT
OPTICAL, VIDEO, .
All the terminals are (from left to right):
HDMI1(ARC), HDMI2, HDMI3, HEADPHONE, ,
Note: When HDMI has an input signal coming from a DVI source then the audio input signal must be
connected to the PC audio input.
USB Media Player RF.
-5-
Panel keys
L - AUDIO - RVIDEOOPTICAL
HDMI1(ARC)
HDMI2 HDMI3
HEADPHONE
R F
USB Media Player
VOL CH
YPbPr
CC MTS VGA
DTV
STRENGTH
TV AV HDMI
EPG
CH LIST
FAV
TV
DISPLAY
S.M
P.M
30 30
3
1
2
1. Short press to turn on the TV.
2. When the TV is on, short press the button to
display the input list.
3. When the TV is on, press and hold the button to
power off the TV.
To Next Page
