Other Information
50 Chapter 5
Back Panel
CH. 3/4 switch Determines the channel to which the TV must be tuned in order to see the
VCR’s picture. Not used when connecting the VCR to the TV using A/V cables.
AUDIO (LEFT and RIGHT) and VIDEO IN jacks Receives signals from another component,
such as another VCR or camcorder, when connected to these jacks. Use the INPUT button on the
VCR or remote control to select the rear video line input A/V jacks (L1) to record from these jacks.
AUDIO (Right and Left) and VIDEO OUT jacks Sends signals from the VCR to another
component, like a TV or another VCR, when the other component is connected to these jacks.
ANT. IN jack Receives a signal from an antenna or cable system when the VCR is attached with
RF cables.
RF OUT jack Passes the VCR’s signal to a TV using the supplied RF cable.
ANT. IN
RF OUT
CH.
VIDEO
AUDIO
OUT
IN
R
L
3 4
