14
ITALIANO
SPECIFICATIONS
µ
÷
±
TT08-A II TT10-A TT20-CXA
ACOUSTICAL
Operating frequency range 65 - 20.000 Hz 60 - 20.000 Hz 60 - 20.000 Hz
Max SPL 128 dB 130 dB 131 dB
Coverage 90° x 70° 90° x 70° 90° x 70°
Crossover point 900 Hz 900 Hz 900 Hz
TRANSDUCERS
Low frequency 8” neo, 2.5” v.c. 10” neo, 2.5” v.c. 2 x 8’’ neo, 2.5’’ v.c
High frequency 1” neo, 1.75” v.c. 1” neo, 1.75” v.c. 1.4” neo, 3.0” v.c.
AMPLIFIER
Total power 2000 Watt 2000 Watt 2000 Watt
Low section 1400 Watt 1400 Watt 1400 Watt
High section 600 Watt 600 Watt 600 Watt
CONNECTIONS
Signal Input/Output XLR, RDNet Ethercon
Power Input/Output Powercon IN/OUT
CONTROLS Bypass, Linear / High Pass, Volume
COOLING Convection
PROTECTIONS Thermal, HF
MECHANICAL
Cabinet Baltic Birch Plywood
Handles 1 top
Hardware 3 x M10 top and bottom; 2 x PIN D.10 and M10 side -
Size (w, h, d) 270 x 450 x 278 306 x 490 x 299 445 x 318 x 450
Weight 11 Kg 12.5 Kg 15.5 Kg
