RCI PDD-FT-3 - Installation Instructions; Details; Features

Details
The PDD-FT-3 board is a fire panel control interface. This board can be used to control DC
output based on a fire alarm control panel. Two outputs switch state on alarm.
Features
• NonLatchingorLatchingmode
• Universal12VDCor24VDCOperation
• Reversepolarityprotected
• NormallyON&NormallyOFFOutput
• OutputLED’sindicatecondition
• OutputscanbeTriggeredwith:
  1)N/OorN/CSwitchwithSupervisedEndofLineResistor(EOL)
  2)N/CSwitchwith(OVR)override
  3)N/CSwitchwith(AUX-IN)auxiliary
  4)Groundonanytriggerinputwhen(GRN)Jumperisenabled
• FormCDPDTRelayIndicatesTriggerStatus
• 3AmpTransferRelayContacts
• Autoormanualresetbyjumperselection
Installation Instructions
1. MountthePDD-FT-3boardinasuitablelocationincloseproximitytothepowersupply.
Note:
a) Groundfaultdetectionwillonlyworkifconductivestandoffsareusedandpower
  supplyenclosureisproperlygrounded.
b) Asthisdevicecanbeusedtopowermultipledevicesensurethatallwiringisofan
  appropriategaugeforthedevicesbeinginstalled.
 c) ThisRCIboardisforuseinacontrolledindoorenvironment.ThePDD-FT-3and
  alldevicesconnectedtoorpoweredthroughthePDD-FT-3shallbeinstalledwithin
  thesamecontinuousbuildingstructure.Installationmustbeinaccordancewith
  localbuildingandfirecodes.CheckwithAuthorityHavingJurisdiction(AHJ)for
  detailspriortoinstalling.
 d) Allpowerlimitedwiringmustbeaminimumof.25”fromnon-powerlimitedwiring.
 e) Maximumtorqueof7in*lbforblackinputandoutputterminals.
2.Connect“INPUT”terminalstooutputofDCsupply,payingcloseattentiontopolarityof
 DCoutputfrompowersupply.
3.ConnectdevicestobepoweredtooutputterminalsofPDD-FT-3controlboard,paying
 closeattentiontopolarityrequirements.Minimum22AWGandmaximumdistanceof 
 6170ft.forfieldwiring.
4.Setjumpers(RST,OVR,AUX,andGRN)asrequiredforproperinstallation.
