RCS FMX-1402 R User Manual

PROFESSIONAL AUDIO MIXER
18
FMX-1402 R FMX-2002
Inputs Mic / Line (Mono) 10 16
Inputs Line (Stereo) 2 2
Total Inputs 30 42
Faders 60 mm 60 mm
Input Impedance - Mic (balanced) 1.3 kohms 1.3 kohms
Input Impedance – Channel Insert 2.5 kohms 2.5 kohms
Input Impedance - All other inputs >10 kohms >10 kohms
Input Sensitivity – Mic -55 dBu -55 dBu
Input Sensitivity – Line (mono / stereo) -35 dBu / -20 dBu -35 dBu / -20 dBu
Output Impedance – Tape 1.0 kohms 1.0 kohms
Output Impedance – Effect Returns or Aux 10 kohms 10 kohms
Output Impedance – All other outputs <120 ohms <120 ohms
Signal-to-noise Ratio >= 90 dB >= 90 dB
Crosstalk >= 85 dB >= 85 dB
Frequency Response (-1.0 dB) 20 Hz – 60 kHz 20 Hz – 60 kHz
THD < 0.05% < 0.05%
Maximum Level Main L/R +28 dB +28 dB
Maximum Level - All other outputs +20 dB +20 dB
Channel High EQ 12 kHz, +/-15 dB 12 kHz, +/-15 dB
Channel High Mid EQ 3.0 kHz, +-12 dB 3.0 kHz, +-12 dB
Channel Mid EQ (Stereo) 2.5 kHz, +-12 dB 2.5 kHz, +-12 dB
Channel Low Mid EQ 800 Hz, +-12 dB 800 Hz, +-12 dB
Channel Low EQ 80 Hz, +-15 dB 80 Hz, +-15 dB
Low Cut 18 dB/octave
at 75 Hz
18 dB/octave
at 75 Hz
Phantom Power +48 V DC +48 V DC
Power Requirement 120/220-240 V AC
50-60 Hz
120/220-240 V AC
50-60 Hz
Power Consumption 50 W 50 W
Dimensions (W x H x D) in mm 483 x 370 x 140 670 x 370 x 110
Weight 7.1 kg 9.1 kg
SPECIFICATIONS TECHNISCHE DATEN
Note: Subject to change without notice. Hinweis: Änderungen vorbehalten.
