9. Compressor – expander device ( only AMWLC – 9DSP1 amplifiers)
Each AMWLC-9DSP1A amplifier’s microphone channel is additionally equipped in compressor –
expander device.
The settings of the compressor - expander parameters are done by the switches and potentiometers
available by unscrewing the small cover on the roof of the amplifier.
Practically, the compressor – expander device let to get the settled volume level independently of the
input signal level.
EKSPANDEREKSPANDER
COMPRESSORCOMPRESSOR
Mic.1 Mic.2
Mic.3
Mic.5
Mic.6
Mic.4
EKSPANDEREKSPANDER EKSPANDEREKSPANDER EKSPANDEREKSPANDER EKSPANDEREKSPANDER EKSPANDEREKSPANDER
COMPRESSORCOMPRESSOR COMPRESSORCOMPRESSOR COMPRESSORCOMPRESSOR COMPRESSORCOMPRESSOR COMPRESSORCOMPRESSOR
On/Off switch
in chosen channel
expander regulation
in chosen channel
compressor regulation
in chosen channel
Mic.7
Mic.8
EKSPANDEREKSPANDER EKSPANDEREKSPANDER
COMPRESSORCOMPRESSOR COMPRESSORCOMPRESSOR
ON
OFF
The view of the plate by unscrewing the cap on the roof of the amplifier.
