Rduch MWL-9DSP1A - Control Card

16
Control card
Date ...........................
Typ .............................
Number ........................
Acoustic control :
Microphone – linear input
Linear input
Phantom power
Timbre regulation of microphone – linear input
Equalizer timbre regulation
Feedback eliminator regulation
100 Hz filter
Inactive microphone mute
“LAST MIC” function
“AUTO/MANUAL” function
Priorities for particular microphone channels
Noise and hum level control
General control :
230V AC power
Fuse
Ground measurements of the device ( according to VDE 0701 norm)
Other connections and connectors control
Optical control of the whole
Notices: ...............................
...........................................
...........................................
...........................................
...........................................
Signature ...............................
Output power
P U Z
200W/100V/50
400W/100V/25
Ù
Ù
600W/100V/16,6Ù
..............................
(Noise generator) control
..................................................
INPUT 0 dB Pre Master
INPUT 0 dB Post Master
Microphone – linear input
Linear input
Recording
Power output ( 40W, 8W, 50V, 70V, 100V)
100 Hz filter
Delay regulation
Feedback eliminator regulation
Zone regulation
Compressor – expander control
Computer control :
Connection with MWL Control program test
Correctness of saving the settings
Factory reset
