Fasten the UPPER ENDS (A and B) to the TOP (E). Tighten
four HIDDEN CAMS.
Step 3
Page 6 www.sauder.com/service 425810
A
B
E
1
2
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Surface with HIDDEN CAMS
Surface without HIDDEN CAMS
Surface with HIDDEN CAMS
Edge with HIDDEN CAMS
Edge with HIDDEN CAMS
