å
Turn forty-six CAM SCREWS (2) into the ENDS (C
and D), TOP (E), SHELF (G), VALANCE (K), BASE (L), SHELF
MOLDINGS (M and N), and END MOLDINGS (O and P).
Step 2
Page 5www.sauder.com/service425810
C
D
G
E
K
L
M
N
O
P
M
M
O
P
2
(46 used)
