RTL8773E Motherboard User Guide
10
·Copyright 2019 Realtek Semiconductor Corporation.
All Rights Reserved.
M2_2 M2_2/LED11&KEY7
M2_3 M2_3/LED5
M2_4 M2_4/LED6
M2_5 M2_5
M2_6 M2_6/SPDIF
M2_7 M2_7/INS_DET
M3_0 M3_0/LED9&KEY5
M3_1 M3_1/LED10&KEY6
M3_2 M3_2/JTAG_nTRST
M3_3 M3_3/JTAG_TDI
M3_4 M3_4/JTAG_TMS
M3_5 M3_5/JTAG_TCK
M4_0 M4_0/AMP_EN
M4_1 M4_1/KEY4
AUX_R AUX_R
AUX_L AUX_L
MIC1_P MIC1_P
MIC1_N MIC1_N
MIC2_P MIC2_P
MIC2_N MIC2_N
MICBIAS MICBIAS
AOUT_LP AOUT_LP
AOUT_LN AOUT_LN
AOUT_RP AOUT_RP
AOUT_RN AOUT_RN
MIC3_P MIC3_P
MIC3_N MIC3_N
Note:
There are two versions of 8773E daughter board, one is the old version with 4ADC pins,
and the other one is the new version with 4 ADC pins. Therefore, it is necessary to note
that the silkscreen on the mother board matches with the new version. The
corresponding relation is as follows.
Besides, if the silkscreen on the daughter board is V7 or above, you can ignore the note
above because the pins of daughter board match with the silkscreen on mother board.
Table 1-2 Partial Pins Mapping between MB and DB
Silkscreen
on MB
QFN40 DB
(old 4ADC)
QFN40 DB
(new 4ADC)
QFN46 DB
(old 4ADC)
QFN46 DB
(new 4ADC)
M0_0 (ADC0)
P0_2 (ADC_2) P0_0 (ADC_0) P0_2 (ADC_2)
P0_0 (ADC_0)
M0_1 (ADC1)
P0_3 (ADC_3) P0_1 (ADC_1) P0_3 (ADC_3)
P0_1 (ADC_1)
