What to do if Rears Paint Sprayer has repeated fuse blow out?
- MMrs. Linda Bryant DDSAug 2, 2025
If your Rears Paint Sprayer repeatedly blows fuses, several issues could be the cause. First, disconnect the power cable and remove lock 29 with a screwdriver. Next, check the rotation of ball 23 using a Ø10 flat screwdriver inserted in the square of stud 18. If the rotation isn't smooth, replace seals 16A, 16B, and ball 23. After checking the rotation, align the notch on stud 18 as illustrated in fig. i, right. If the rotation of ball 23 is smooth, check the motor unit 1 by connecting the blue and brown wires to a 12Vdc line; correct rotation is 90° between microswitches. For a black cap motor, with the brown wire to the (+) pole, the gearmotor cam position should be as illustrated in fig. iii, right. If unit 1 still doesn't rotate correctly, replace the entire unit.
