RecPro RP-RANGE-17BL - Page 25

053 Control Panel
027 Chimney Holder 001 Oven Burner Pipe
054 Igniter
028 Viewing Lamp 002 Oven AL Pipe
055 Rear Burner Valve
029 Front Glass 003 Temp Control Holder
056 Front Burner Valve
030 ScrewM4X4 004 ODS
057 Oven Thermostat
031 Hinge B
005 ODS Holder
058 Knob Base
032 Chimney Decoration Panel 006 Side Cavity Plate
059 Decoration Ring
033 Rear Cover 007 Oven Burner Baffle Plate
060 Igniter Knob
034 Gasket for Top Glass 008 Up Cavity Plate
061 Lamp Switch
035 Grill
009 Front Burner Pipe
062 LED PCB
063 Knob
064 Door Middle Glass Holder
036 Hinge A
037 Folding Cover Glass
010 Right Hob Table Plate
011 Rear Cavity Plate
038
065 Door Inner Frame
Docking Nut 012 Right Burner Pipe
039 Hob Table 013 Burner Holder
066 Door Inner Frame Holder
067 Door Handle
040 Rear Gas-In Pipe 014 Grill Silicon Gasket
068 Door Outer Frame
041 Insulation Plate
015 Nozzle Base Holder
069 Door Middle Glass
042 Regulator
016 Oven Burner Nozzle
070 Door Outer Glass
043 Hob Table Fixer
017 Rear Burner Ignition Pin
071 Door Inner Glass
044 Front Gas-In Pipe
018 Nozzle Base
072 Door Glass Holder
045
G
l
a
s
s
C
o
v
e
r
F
i
x
e
r
(
F
r
o
n
t
)
019 Burner Cover
073 Door Hinger
046 Gas-In Pipe Holder 020 Gas-In Connector Cover
074 Bottom Cover
047 Front Cavity Plate 021 Left Burner Pipe
075 Oven Burner
048 Left Hob Table Plate 022 Mica Sheet
076 Bottom Cavity Plate
049 Side Cover
023 Chimney Cover (Bottom)
077 Bake Rack
050 Door Silicon Sealing Ring 024 Front Burner Ignition Pin
078 Door Hinge Holder(Left)
051 Control Panel Holder (Left) 025 Fire Distributor
079 Door Hinge Holder(Right)
052 Control Panel Holder (Right) 026 Chimney Cover
25IPage
