Chapter 2.
3
Configuring an APC Switch as a Fence
Device
This chapter provides the procedures for configuring an APC switch as a fence device in a Red Hat
cluster using the Conga configuration tool.
Figure 2.1, “Using an APC Switch as a Fence Device” shows the configuration this procedure yields.
In this configuration a three node cluster uses an APC switch as the fencing device. Each node in the
cluster is connected to a port in the APC switch.
Figure 2.1. Using an APC Switch as a Fence Device
2.1. APC Fence Device Prerequisite Configuration
Table 2.1, “Configuration Prerequisities” summarizes the prerequisite components that have been set
up before this procedure begins.
Component Name Comment
cluster apcclust three-node cluster
cluster node clusternode1.example.com node in cluster apcclust configured with APC switch to
administer power supply
