MAX
®
S-Series LED Installation & Operation Manual’s
6
Assembly
Detailed instructions for the complete assembly of the MAX
®
S can be found in the accompanying graphic manual.
It is important to assemble the MAX
®
S in the order indicated. The following information compliments the graphic
manual.
If you are planning on pre-assembling the cabinet before transporting the MAX
®
S to its final location, complete
only the stages 1 & 2 as per the graphic manual.
NOTE: Left and Right designations are when looking from the front of the Aquarium.
Tools
The assembly requires the following tools:
• Adjustable torque Power Drill/Driver (at least 12V) with a crosshead bit
on a 5cm / 2” extension.
Do not use an impact power driver
• Regular crosshead and flat screwdrivers
• Rubber Mallet
• Spirit level (at least 60cm / 2”)
Components
• The MAX
®
S system includes the following main components:
• MAX
®
S type glass aquarium with integral top-up reservoir
• Cabinet (self-assembly)
• MAX
®
S LED lighting unit
• Power Center
• Glass Sump including micron filter bags, Carbon media and Float valve
for automatic top-up
• Internal Piping
• C-Skim 1800 Protein Skimmer
• Main return pump
• Circulation pumps (number according to model)
Color pack:
• Cabinet sides and doors
• Trim pack for aquarium, cabinet and lights
