Red Sound SoundBITE - Page 4

4
PAGE
Connections
CONNECTIONS
DJ MIXING DESK
ALTERNATIVE ‘LOOPS OUT’ CONNECTION
FOR USE WITH 2 CHANNEL MIXING DESK +
VINYL RECORD DECK SYSTEM
HEADPHONE
MONITOR
OUTPUT
INPUT CABLE [SUPPLIED] -
6.3mm TO RCA STEREO
2 x OUTPUT CABLES [SUPPLIED] -
1 x RCA TO TWIN RCA
STEREO RCA TO RCA
CONNECT TO
SPARE INPUT
CHANNEL ON
MIXING DESK
R
R
RL
L
L
LOOPS OUT
LOOPS OUT
INPUT POWER
[ 9vDC ]
-
+
Red
Sound
R
R
L
L
R
L
TO
AC WALL
SOCKET
RED
PSU
R
LL
R
PHONO PHONOCD/LINE CD/LINE
CHANNEL 2 CHANNEL 1
SIGNAL
GND
SIGNAL
GND
The unused CD/line
inputs on a 2 channel
desk + vinyl deck
system can be
connected to the
[LOOPS OUT] sockets
using the special 1 into
2 RCA cables supplied.
In this way, the loops
can always be brought
in on the crossfader by
switching the cue
channel to CD/Line.
ANALOG TURNTABLE ANALOG TURNTABLE
HEADPHONES
CONNECT TO
FRONT PANEL
SOCKET
SoundBITE - DJ Loop Sampler
SoundBITE
AUTO - LOOP MODULE
