Mounting Options
MOUNTING OPTIONS
MIXING DESK
M3 SCREW
(LENGTH = 6mm MAX)
BRACKET
M6 SCREW
M6 NUT
DJ MIXING DESK TOP PANEL
19” RACK MOUNT HOLE
END VIEW
PLAN VIEW
Rotate the chrome brackets to line-
up with the 19” rack mounting holes
on your mixing desk.
19” RACK
Hole pitch
range =
Min 90mm
Max 240mm
Alternatively, you can use the supplied rubber feet or double-sided sticky pads to flat-mount SoundBITE in any
convenient location.
