Redarc SRP0240 - Specifications; Product Dimensions; General Specifications

SPECIFICATIONS
DIMENSIONS
GENERAL SPECIFICATIONS
System Voltage
12V 24V
Battery Type
AGM/Gel SLA Calcium AGM/Gel SLA Calcium
Maximum Voltage*
14.4V 14.6V 14.8V 28.8V 29.2V 29.6V
Float Voltage*
13.6V 13.6V 13.6V 27.2V 27.2V 27.2V
Maximum Input Voltage
30V 55V
Battery Voltage Range
9 -15V 18 - 30V
Boost Time
2 hours
Standby Current Draw
4mA
Nominal Current Draw
10mA
Remote Connection 8-pin RJ-45
Temp. Compensation -30mV/12V/°C
Terminals 4mm²
Operating Temp. -35°C to +50°C
*Charge profile voltages will change with temperature compensation
153mm
146mm
50mm 76mm
37mm
