5
1.0 TECHNICAL SPECIFICATIONS.
Model 7316
Working width 1.60 mtr (5’4”)
Working depth Up to 300 mm (12”)
Tractor speed @ 500 rev’s at PTO
Hole spacing 65 mm (2-1/2”)
Hole spacing 130mm( 5”)
Hole spacing 195mm(7-1/2”)
Up to 0.85 km/h (0.55 mph)
Up to 1.75 km/h (1.10 mph)
Up to 2.60 km/h (1.60 mph)
PTO speed: (max) Up to 500 rpm
Weight 670 Kg (1480 lbs)
Hole spacing side-to-side 130 mm (5”) @ 18 mm (3/4”) holes
65 mm (2.5”)@ 12 mm (1/2”) holes
Hole spacing in driving direction 25 – 195 mm ( 1 - 7-1/2”)
Recommended tractor size 28 HP with lift capacity of minimum 825 Kg.
(1815 lbs)
Capacity (maximum)
Spacing 65 mm (2-1/2”)
Spacing 130mm (5 “)
Spacing 195mm (7-1/2”)
Up to 1360 sq.mtr (12300 sq ft)/ hour
Up to 2800 sq.mtr (25500 sq.ft)/ hour
Up to 4200 sq.mtr (38000 sq.ft)/ hour
Shipping dimensions 1700 x 800 x 1200 mm
(68”x 32”x 48”)
Maximum tine size Solid 18 x 300 mm (3/4”x 12”)
Hollow 25 x 250 mm (1”x 10”)
Slip clutch setting PTO Maximum 500 Nm. (4400 lb.inch.)
Three point linkage 3- point CAT 1 .
Transmission oil Use 80W90 (5 liter).
Lubrication grease EP 2
Standard items Set solid tines 12/300 (1/2”x 12 )..
Front and rear roller
3- shuttle gearbox
Toolbox with combi tool
