Redexim VERTI-DRAIN 7416 - Technical Specification

7
1.0 TECHNICAL SPECIFICATIONS
Model
7416
Working width
1.60 m (63”)
Working depth
Tot 350 mm (14”)
Tractor speed @ 500 rev’s at
PTO
Hole spacing 65 mm (2-1/2”)
Hole spacing 130 mm ( 5”)
Hole spacing 195 mm (7-1/2”)
Up to 0.85 km/h (0.55 mph)
Up to 1.75 km/h (1.10 mph)
Up to 2.50 km/h (1.56 mph)
PTO speed: (max)
Up to 500 rpm
Weight
870 Kg (1914 lbs)
Hole spacing side-to-side
130 mm (5”) @ 18 mm (3/4”) holes
65 mm (2.5”)@ 12 mm (1/2”) holes
Hole spacing in driving direction
25 – 195 mm ( 1 - 7-1/2”)
Recommend minimum tractor
size
35 HP with lift capacity of minimum 1050 Kg
(2310 lbs)
Capacity (maximum)
Spacing 65 mm (2-1/2”)
Spacing 130mm (5 “)
Spacing 165mm (6-1/2”)
Up to 1360 sq.mtr (12300 sq ft)/ hour
Up to 2800 sq.mtr (25500 sq.ft)/ hour
Up to 4200 sq.mtr (38000 sq.ft)/ hour
Shipping dimensions
1700 x 1000 x 1700 mm
(68”x 40”x 68”)
Maximum tine size
Solid 24 x 350 mm (1”x 14”)
Hollow 32 x 300 mm (1-1/4”x 12”)
Slip clutch setting PTO
Maximum 800 Nm. (7080 lb.inch.)
Three point linkage
3- point CAT 1.
Transmission oil
80W90 – 5 liter
Lubrication grease
EP 2
Standard items
Set solid tines 18/300 (3/4”x12) with adapters
Front and rear roller
3- shuttle gearbox
Toolbox with combi tool
